Writing Evolveum Documentation

Last modified 03 Jun 2021 09:01 +02:00

This document provides overview of how the docs site works, and how to write and maintain Evolveum documentation.

Overview

The "docs" site is built using Jekyll static site generator, spiced up with Asciidoctor and other goodies. The site is generated from the "sources" into static HTML files. There is no dynamic interpretation of HTTP requests, however there is some client-side JavaScript to improve site presentation. Everything has to be generated before the first request comes, including headers, footers, navigation and everything else.

Site sources are maintained in GitHub docs repository. There is an automatic hook in github, that triggers rebuild of the site when the source code is updated.

AsciiDoc

Bulk of the documentation is maintained in AsciiDoc format. If you are new to AsciiDoc, please have a look at AsciiDoc Writing Guide for an introduction. If you are familiar with AsciiDoc, you can start writing your documents right away. However, please keep the "one sentence per line" convention.

Use AsciiDoc whenever possible. Jekyll that runs this site allows also other documentation formats, such as HTML or Markdown. Use HTML only in case AsciiDoc would not do the job, or it would be very complicated. Do not use Markdown at all. We do not like Markdown here.

Creating Pages

Site source code has almost exactly the same structure as the generated website. A picture stored as midpoint/foo/bar.png in the site source code will be published as https://docs.evolveum.com/midpoint/foo/bar.png. For text documents, Jekyll automatically converts them and hides file extension. Therefore midpoint/foo/bar.adoc becomes https://docs.evolveum.com/midpoint/foo/bar/.

AsciiDoc pages can be created in a very straightforward way. Just place your document in a suitable directory, make sure it has adoc extension and that’s it. The document should be well-formatted according to the AsciiDoc Writing Guide. In that case Jekyll takes all the data and meta-data from the document itself, properly setting document title, placing it in the navigation and all the other things. AsciiDoc is strongly recommended method of creating and maintaining documents. IntelliJ IDEA has a very convenient plugin for AsciiDoc editing. Developers and engineers would probably like to clone the site sources from gitlab and open them as a project in the IDEA.

While Jekyll does almost all the work transparently for AsciiDoc documents, other document types need a couple of additional things. Especially HTML documents usually need a place to specify document title and other meta-data. This place is called front matter and it is located at the beginning of the document:

---
layout: page
title: IAM Best Practice
nav-title: Best Practice
display-order: 700
---
<p>
    These are the things that work in IAM deployments.
</p>
... other HTML elements ...

In this case, the front matter sets document title, navigation title and display order. It also specifies page layout (see later), and it may also specify almost arbitrary data and meta-data for the page. Front matter is YAML-formatted. However, the most common form of front matter is just a simple attribute-value list as the one shown above.

AsciiDoc documents may also specify front matter attributes if needed. In AsciiDoc, the attributes need to be specified in AsciiDoc format with page- prefix. The front matter above can be expressed in AsciiDoc like this:

= IAM Best Practice
:page-nav-title: Best Practice
:page-display-order: 700

These are the things that work in IAM deployments.

... other AsciiDoc things ...

However, AsciiDoc documents usually do not need any front matter or attributes at all. E.g. in this case we did not even need to specify title and layout. Title was taken from AsciiDoc title, and page layout was applied by default. Everything is easier with AsciiDoc.

Directory Structure

Site source code follows closely the resulting site structure, except for some URL translations. Such translations usually apply to asciidoc documents and index files (index.html, index.adoc). It is perhaps best to explain the URL translation on examples:

Source file location URL Note

index.html

https://docs.evolveum.com/

Site home document

foo/bar.adoc

https://docs.evolveum.com/foo/bar/

foo/bar.html

https://docs.evolveum.com/foo/bar/

foo/index.adoc

https://docs.evolveum.com/foo/

index.adoc is a special name that stands for the entire directory.

foo/index.html

https://docs.evolveum.com/foo/

index.html is a special name that stands for the entire directory.

foo/bar.png

https://docs.evolveum.com/foo/bar.png

Image files (.png, .jpg), PDFs (*.pdf) and similar data files are not translated.

Which means that there are two ways how to store your document:

  • foo.adoc: This is suitable for simple documents that do not have any embedded data. It can work well even for long documents.

  • foo/index.adoc: Good method for documents that contain embedded data, such as pictures. The best strategy is to place the pictures into the same directory as index.adoc. You will have everything neatly stored in one place.

Both methods will results in the same URL. URL is all that matters for the web. You can change foo.adoc to foo/index.adoc at any time and Jekyll will generate the same URL. Therefore you can easily start with foo.adoc and then switch to foo/index.adoc later if needed.

We love links. Please, put a lot of links in your documents. There are two ways how to do it: link or xref.

Xref Macro

Xref macro (xref) is intended for cross-referencing in a document and between documents. We use the xref macro for links in our site:

Please see xref:/foo/bar.adoc[FooBar page] for more details.
You can also use simple xref:bar.adoc[], document title will be automatically used as link text.

The xref macro points to the source file, not to the URL. In this case Evolveum plugins take care of proper translation of file names to URLs. However, you can also use directory URLs, just make sure they end with slash (/) character:

This is a link to xref:/midpoint/projects/midprivacy/[MidPrivacy initiative].

The plugin checks that the xref points to an existing site page. There will be an error message during the build if the link is broken.

Implementation details
This is not a default behavior of Asciidoctor or Jekyll. This functionality was implemented as Asciidoctor extension in evolveum-jekyll-plugin gem. There is a custom inline macro processor for the xref macro that looks up appropriate Jekyll page, determines the URL and (optionally) a link title.

AsciiDoc has a link macro to do generic HTML linking.

Maybe you wonder link:https://en.wikipedia.org/wiki/Foobar[what foobar is].

You may also write links without explicit link: prefix, as asciidoctor defined http and https as macros for convenience:

Maybe you wonder https://en.wikipedia.org/wiki/Foobar[what foobar is].

Neither Jekyll nor Asciidoctor checks that the link is valid. You can link to whatever you want, but you are responsible to make sure that the link is not broken.

Use the link macro for external links only (links that point outside of docs site). For internal links use xref macro instead.

Bug Macro

Link to an issue can be done using the bug macro:

Due to bug:MID-1234[] issue, you are pretty much out of luck.
Also, beware of bug:MID-4321[a particularly nasty issue] in midPoint 1.8.
Maybe it is finally time to upgrade to midPoint 4.3?

Table Of Contents

Document table of contents (ToC) can be automatically generated. This mechanisms if controlled by page-toc asciidoc variable:

= AsciiDoc Fairy Tale
:page-toc: top

This is a nice short fairy tale ...

The variable may contain several values, changing the type of ToC:

page-toc value description

top

ToC at the top of the document, right after the main title.

float-right

ToC floating in a "frame" on the right side. The document text is wrapped on the left side. However, if the introduction is too short, the headings may not fit well.

float-left

ToC floating in a "frame" on the left side. Experimental.

Implementation details
The page-toc asciidoc variable translates to toc Jekyll variable. Jekyll is using this variable in the templating engine (_layouts/page.html) to ivoke special tocify_asciidoc filter on asciidoc document. The value of this variable is used to set the CSS style.

Page Warnings

Docs pages may easily include common "warnings" at the top of a page.

If you are using midPoint versions, it is recommended to enclose them in double quotes. Jekyll interprets variables as JSON/YAML, therefore version 1.10 will be interpreted as number. The it will be considered to be the same as 1.1. Specifying the version quoted as "1.10" solves the problem.

Experimental

Warns that the page describes an experimental functionality:

= Foo Feature
:page-experimental: true
Do not confuse the page-experimental attribute with experimental attribute. The experimental attribute turns on Asciidoctor experimental features (suc as GUI button and menu links), while page-experimental attribute marks page content as experimental.

Since

Notice that this functionality is available only from a certain version:

= Foo Feature
:page-since: "4.3"

Or in a slightly more complex case:

= Foo Feature
:page-since: "4.0"
:page-since-improved: [ "4.1", "4.2" ]
:page-since-description: This feature is expected to reach its full functionality in version 4.8.

This feature was introduced in 4.0, improved in 4.1 and 4.2, and there is additional description that will be added to the notice.

More than one version can be specified if needed:

= Foo Feature
:page-since: [ "4.1", "4.0.2" ]

The "since" notice can be included inside the page, e.g. under a specific heading. This comes handy when describing functionality improvements that came later. In this case it is required to use Liquid include mechanism:

= Foo Feature

Blah blah blah, same old functionality as always ... blah blah blah.

== New Cool Improvement

++++
{% include since.html since="3.5" %}
++++

This is a very cool improvement that changes everything ....

The ++++ marks are necessary. Those mark Asciidoc passthrough block. The Liquid include produces HTML, not asciidoc. We need to tell asciidoc that this block should be "passed through" to output without processing.

Deprecated

Notice that this functionality is deprecated:

= Foo Feature
:page-deprecated: true

Alternatively, a version may be specified:

= Foo Feature
:page-deprecated-since: "4.3"

Obsolete

Notice that this functionality is obsolete:

= Foo Feature
:page-obsolete: true

Alternatively, a version may be specified:

= Foo Feature
:page-obsolete-since: "4.3"

Replaced By

Deprecated and obsolete pages may specify an optional replacement URL:

= Foo Feature
:page-replaced-by: /features/bar/

Liquid Templating

Jekyll is using Liquid templating language. If is very simple templating language that is using "curly bracket" markup: {{, }}, {%, %}. Liquid can be used to add basic logic to the documents, such as this:

        ...
        <h1>{{ page.title | escape }}</h1>

        {% if page.toc %}
        <div class="toc-{{page.toc}}">
            <title>Table of Contents</title>
            {{ page.document | tocify_asciidoc }}
        </div>
        {% endif %}
        ...

See Liquid documentation for the details.

There are some custom Liquid tags that are implemented by Evolveum plugin, such as {{ childern }}.

Liquid is enabled in all AsciiDoc documents by default. There is a slight chance Liquid may interfere with AsciiDoc formatting. Therefore, please be careful when using curly brackets in asciidoc documents. There are rare cases when Liquid interferes with your document, such as this document that needs to include lot of liquid example code. In such cases use Liquid tags raw and endraw to avoid Liquid processing. You can have a look at the source code of this document for an example.

Special Files and Directories

Most of the files in the Jekyll project are documents. But there are some special directories and files:

Directory Description

_config.yml

Global configuration of the site. There are global variables such as site name, base URL and so on. There is also Jekyll configuration, such as specification of theme and list of plugins.

Gemfile

Ruby files that specifies gems that are used by this site. Gems are Ruby components (libraries). In this case, the gems provide additional functionality to the site.

_data

Jekyll data files. Data files are small databases that contain structured data. The data are used in some of the pages that display them in user-friendly form.

_layouts

Jekyll layouts. Layouts are templates for pages. If there is a repetitive page, it can be a good idea to set up a template (layout) for it. The usual layouts are default and page. However, these are part of Evoleveum theme, therefore they are not present of site _layouts directory.

_includes

Include files. Small parts of HTML code that are often repeated in pages can be placed here. This snippets can be included in other pages by using {% include …​ %} Liquid tag.

_sass

Syntactically Awesome Style Sheets (SASS) files that set up the site look and feel. SASS files are automatically compiled to CSS files for the website. Most SASS files are present in the template, the site itself will usually need only to set some variables.

assets

Website assets such as images, fonts, icons and other decorations.

Generally speaking, the files and directories that start with an underscore (_) are not directly translated to website content. Such files influence the way how the site behaves. However, many files are transformed to website content indirectly. E.g. the SASS stylesheets in _sass are transformed to CSS and published on the website.

Navigation is an important aspect of a website that is packed with documents. There was no ready-made navigation mechanism for Jekyll, therefore we had to develop our own. It is part of Evolveum Jekyll plugin and supported by Evolveum theme.

The navigation tree generated automatically for all documents on the site. There is nothing special to do when a new document is added. It will be automatically added to the navigation tree. However, you may want to customize the way how the navigation mechanism displays your document.

Navigation tree will take the title of your document by default. However, your title may be too long and may want to have shorter title in the navigation tree. You can set the navigation title by using nav-title page property, like this:

= IAM Best Practice
:page-nav-title: Best Practice

... page content here ...
---
layout: page
title: IAM Best Practice
nav-title: Best Practice
---
... page content here ...

Sorting

Navigation tree is sorted alphabetically based on document title by default. However, there may be a need to sort the pages explicitly. This can be achieved by using display-order page property. The display-order contains a numeric value. The pages at the same navigation level will be sorted by the value of display-order. Pages that have the same display-order will be sorted alphabetically. The default value of display-order is 100.

= Foo Bar
:page-display-order: 800

... page content here ...
---
layout: page
title: Foo Bar
display-order: 800
---
... page content here ...

Visibility

All the pages are publicly visible by default. However, there may be a need to hide a page. Maybe we do not want to complicate the navigation with our page. Maybe the page is just a draft and we do not want to publicly publish it just yet. There may be variety of reasons.

Page visibility can be controlled by visibility page property. The property can take several values:

Visibility Description Shown in navigation Shown in sitemap.xml

visible (default)

Publicly visible page.

Yes

Yes

draft

Document intended for public publication, but it is not ready yet.

No

No

hidden

Page that we do not want to advertise to the public audience in any way. Maybe some testing pages.

No

No

data

Public data file. This is a document, but it is not HTML-presentatble. Maybe used for PDF presentation slides, binary downloads and so on. There needs to be some HTML/AsciiDoc page that points to this file.

No

Yes

auxiliary

Auxiliary or helper page, but still public. Page for special purpose.

No

Yes

system

System object. Needed for the page to work properly. Not really a "document".

No

No

Set the property like this:

= Foo Bar
:page-visibility: hidden

... page content here ...
---
layout: page
title: Foo Bar
visibility: hidden
---
... page content here ...
Hidden pages are still public.
Everything that is present on the site is ultimately public. Hiding a page will remove it from the navigation and site maps. The users will not be able to find the page on the site, and we will do what we can do to hide it from search engines. But the page will still be accessible if the user knows the URL or looks at source code. The page is just hidden, it is not protected.

Child Pages

There may be a need to list your child pages at your page. This is usually used on various index pages that you do not want to maintain manually. You can use {% children %} Liquid tag for this:

= Project Foo Documents
:page-liquid:

Blah blah blah ... the pages:

++++
{% children %}
++++

<p>That's it</p>
---
layout: page
title: Project Foo Documents
---
<p>Blah blah blah ... the pages:</p>

{% children %}

<p>That's it</p>

Aliases

There may be a need to show the same page at several places in the navigation tree. Aliases can help with that:

= MidPrivacy Initiative
:page-alias: { "parent" : "/midpoint/" }
---
layout: page
title: MidPrivacy Initiative
---
alias: { "parent" : "/midpoint/" }

This specification will make the MidPrivacy Initiative appear under the /midpoint page, in addition to the normal location of the MidPrivacy Initiative page. The URL link will point to the correct (canonical) page URL. The alias influences the navigation structure only, it does not influence page URLs.

The alias can specify even more details for the "symlink" in the menu:

= MidPrivacy Initiative
:page-alias: { "parent" : "/midpoint/", "title" : "MidPrivacy", "display-order" : 300 }

Stubs

Jekyll (or rather our plugin) will generate "stub" pages for documents that are missing in the tree. For example, let’s assume that we have foo/bar.adoc and /foo/baz.adoc, but we do not have foo.adoc nor foo/index.adoc. In that case Jekyll will automatically generate "stub" for /foo/. The "stub" is a simple page that just lists the children pages.

The stub will have an ugly title, derived from the URL. In the above example, the title of the stub will be simply foo. Therefore it is still recommended to explicitly create a simple page:

foo/index.adoc
= Foo Documents
:page-liquid:

++++
{% children %}
++++
foo/index.html
---
layout: page
title: Foo Documents
---
{% children %}

Hiding Subtrees

You may want to hide entire subtree. This can also be achieved with a simple index document:

foo/index.adoc
= Foo
:page-visibility: hidden
:page-liquid:

++++
{% children %}
++++
foo/index.html
---
layout: page
title: Foo
visibility: hidden
---
{% children %}

This document hides the entire foo/* subtree, as the navigation algorithm will not dive into a hidden page. However, page breadcrumbs will still work, even in the hidden subtree. Therefore other documents in the subtree may be discovered using breadcrumbs.

Top Navigation Bar

Top navigation bar is special. There is very little space, therefore only selected pages can appear here. The content of the navigation bar is controlled by _data/navbar.yml file:

_data/navbar.yml
- label: MidPoint
  url: /midpoint/

- label: IAM Introduction
  url: /iam/

- label: Book
  url: /book/

- label: Identity Connectors
  url: /connectors/

- label: Talks
  url: /talks/

General Tips and Limitations

  • Avoid using newline characters in inline macro parameters:

    Bad
    xref:other/page.adoc[Some other
    page]
    Good
    xref:other/page.adoc[Some other page]

    Inline macros with newline in parameters do not work. We are not sure why is that, they just don’t work.

Moving Pages

Generally, the pages should not be moved. Once the page is created on a certain URL, it should stay on that URL. Of course, it is OK to change foo.adoc to foo/index.adoc, as the URL stays the same. But the pages should not be moved in a way that changes the URL.

When the page really needs to be moved, there is a mechanism how to leave behind a redirect from the old URL to new URL:

/support/index.adoc
= MidPoint Support
:page-moved-from: /midpoint/support/

Bla bla
/support/index.html
---
layout: page
title: MidPoint Support
moved-from: /midpoint/support/
---
Bla bla

The moved-from attribute specifies the local part of the old URL. Jekyll will generate a redirect from the old URL to a new URL of the page. In this case, Jekyll will redirect /midpoint/support/ to /support/.

In a case that an entire subtree needs to be moved, the * notation can be used to set up a subtree redirect:

= MidPoint Support
:page-moved-from: /midpoint/support/*

Bla bla
---
layout: page
title: MidPoint Support
moved-from: /midpoint/support/*
---
Bla bla
Implementation detail
Jekyll generates the redirects as a series of Apache RewriteRule statements in .htaccess file. The code is in the jekyll-redirect-plugin.rb file in the evolveum-jekyll-plugin project.

Data Files

Jekyll data files are small databases that can be used to hold structured data. The data files are placed in the _data directory. The files are formatted in YAML, like this:

_data/talks.yml
- id:  2020-09-data-provenance-workshop
  title: Data Provenance and Metadata Management in IdM
  date: 2020-09
  event: Evolveum on-line workshop
  author: Slávek Licehammer, Radovan Semančík
  slidesFile: 2020-09-data-provenance-workshop.pdf
  videoUrl: /media/2020-09-10-data-provenance-workshop.mp4

- id: 2020-05-whats-new-in-midpoint-4-1
  title: What's New In MidPoint 4.1
  date: 2020-05
  event: Evolveum Webinar
  author: Radovan Semančík
  slidesFile: 2020-05-whats-new-in-midpoint-4-1.pdf

The files are usually used in HTML pages, with a help of Liquid tags:

talks/index.yml (simplified)
---
layout: page
title: Talks
---
<dl>
{% for talk in site.data.talks %}
  <dt><a href="files/{{ talk.slidesFile }}">{{ talk.title }}</a>
  </dt>
  <dd>
        {{ talk.date }}, {{ talk.author }},
        {% if talk.eventUrl %}<a href="{{ talk.eventUrl }}">{% endif %}{{talk.event}}{% if talk.eventUrl %}</a>{% endif %}{% if talk.description %}:{% endif %}
        {{ talk.description }}</dd>
{% endfor %}
</dl>

The talks.yml data file will be present in Liquid variable site.data.talks. As the content of talks.yml file represents a list, the content of site.data.talks can be processed by simple for liquid tag.

Liquid tags {% and %} control the flow of the template. The {{ and }} tags are used for displaying data. The {{ talk.data }} and {{ talk.author }} refer to the date and author fields in the talks.yml file.

Simple, isn’t it?

If you want to create a new database, just create a new _data/foo.yml file and fill it with data. Content of the file will be present in the site.data.foo variable.

Layouts

Jekyll layouts are templates to construct particular type of page. The most common layout is page, which is used for vast majority of pages in our sites. The page layout has a pre-set formatting for page title, breadcrumbs, navigation tree and all other necessities. However, sometimes there is a need for a different layout. For example, site home page (landing page) usually does not have a title. Having empty HTML tags for the title can ruin the design. Therefore, there is special home layout that is almost the same as page layout, but it does not have a title.

Evolveum theme contains following layouts ready to be used:

Layout Description

page

The most common layout. It has title, breadcrumbs, navigation tree and all the other goodies.

home

Layout for site home page. It does not have title and breadcrumbs. It still has navigation tree to let users access site content.

default

Barebones layout. It contains only the most necessary things that all web pages on our site must have, such as header and footer.

You can create your own custom layouts if you need to. Just place them into the _layouts directory. You can use the exercise layout on docs as an inspiration.

Stylesheets

Site look and feel is given by stylesheets (SASS and CSS) combined with the layouts. Layouts dictate which HTML elements are used in the page, stylesheets specify how the elements look like.

The design is a living thing. The design has to be responsive, it has to adapt to various devices. We want to display rich navigation tree on big notebook displays, but we do not have a place for that on mobile phones. Creating stylesheets for such a design is a difficult work. Therefore we are not starting from scratch. We are basing our design on Bootstrap framework.

The stylesheets are created and maintained in a form of Syntactically Awesome Style Sheets (SASS). The SASS files are automatically compiled into ordinary CSS files by Jekyll. Most of the stylesheets are part of Evolveum theme and there is usually no need to change them. Some look and feel of the site can be adapted by changing values of SASS variables.

There is a special Evolveum theme applied to this site. The theme specifies basic site design, such as CSS/SASS styles and HTML page templates. The theme contains stylesheets (SASS), page layouts, fonts, icons, evolveum logo and anything else that is used on all our sites. The theme has file structure that is almost the same as Jekyll site structure.

The theme is supplemented by Evolveum Jekyll plugin, which adds more complex elements, such as the navigation. The plugin is a small piece of Ruby code that add some features to Jekyll.

Both the theme and the plugin are designed to be used as Ruby gems. There is a build.sh script that builds and installs the gems.

The use of the theme and the plugin is specified in _config.yml file in the site.

When the site refers to page layout, that layout is taken from the theme, from _layouts directory. Our page layout file (_layouts/page.html) specifies the structure of pages on our sites. This layout contains Liquid tags to render navigational elements ({% breadcrumbs %}, {% navtree %}). These are custom Liquid tags that are implemented in evolveum-jekyll-plugin.

Please note that the content of docs site is licensed under the terms of Creative Commons Attribution-NonCommercial-NoDerivatives 4.0 International (CC BY-NC-ND 4.0) license. There are limitations to the use of both the content of the site, and its source code. Please also note, that the license does not cover use of trademarks, which may be used on this site.

Generally speaking, Contributor License Agreement (CLA) is needed to contribute to the content of this site.

Legacy

Most of the documentation on this site was migrated from Evolveum Wiki, that was used to maintain the documentation before 2021. There is some legacy from the old times, such as the pages contain wiki-name and Wiki metadata variables.

Wiki Macro

Linking to the wiki page can be done wiki wiki macro:

Please see wiki:Architecture+and+Design[] page for more details.

Or maybe you want to see wiki:Design+Notes[this page].

The wiki macro will automatically generate appropriate URL to docs page if the page was migrated to docs. The macro will indicate an error if such a page cannot be found.

Implementation detail
The wiki macro is looking for a page with matching wiki-name variable.
